MIL-PRF-5806H
3.3.16.6 Individual hoisting devices. The rings, eyes, or lugs shall be designed such that the
loaded box can be lifted free of the ground by any single ring, eye, or lug in accordance with
4.4.19.6.
FIGURE 1. Stacking guide
3.3.16.7 Tiedown/towing devices. These devices shall have a minimum inside diameter of 3
inches. These devices, when not in use, shall not project beyond the dimensions of the box. The
devices shall be subjected to loading as outlined in 4.4.19.7 without yielding or failure or
deformation of the box.
3.3.16.8 Pulling. The loaded box shall be capable of being pulled from each end without damage
to the blade or deformation of the box (see 4.4.19.8).
3.3.16.9 Pushing. A loaded box, when tested in accordance with 4.4.19.9, shall show no
evidence of damage to the blade or deformation of the box when pushed with a forklift.
3.3.17 Environmental conditions. The storage and shipping box shall be capable of meeting
requirements of this specification subject to the following adverse environmental conditions:
Temperature
-25° F to 160° F
Relative humidity
100%
7
