MIL-PRF-11264F
TABLE IV. Graduated drop and impact test heights.
Gross weight of
Cornerwise-drop test
container and
and
contents
edgewise-drop test
Impact tests
Pendulum Incline
Height of drop
impact
impact
kilograms
(millimeters) (inches) (mm) (in.) (mm) (in.)
(lb)
Through 113 (250)
760
30
360 14 2130 84
Over 113 (250) thru
610
24
280
11
1680 65
227 (500)
Over 227 (500) thru
460
18
200
8
1220 48
454 (1000)
Over 454 (1000)
300
12
130
5
760
30
4.6.2.2.5 Vibration test. To determine conformance to 3.3.1.2.5, the vibration test shall
be conducted in accordance with the ASTM D4169.
4.6.3 Cover construction. Visual inspection shall be used to determine conformance to
3.3.2.1.
4.6.3.1 Inspection hinges. Visual inspection shall be used to determine conformance to
3.3.2.3.
4.6.3.2 Drainage. To determine conformance to 3.3.2.4, the unloaded container shall be
submerged in water for 2 minutes, then allowed to drain in an upright position in a dry place for
not more than 15 minutes. A visual inspection immediately following the 15 minute drainage
period shall be used to determine conformance to 3.3.2.4.
4.6.3.3 Ventilation. To determine conformance to 3.3.2.5, a visual inspection shall be
made to ensure that ventilation holes are provided.
4.6.3.4 Water resistance. To determine conformance to 3.3.2.6, test the container
according to ASTM D951 using the high intensity water spray test.
4.6.3.5 Axle supports. Demonstration and visual inspection shall be used to determine
conformance to 3.3.2.7.
4.6.3.6 Built-in cradle. Demonstration and visual inspection shall be used to determine
conformance to 3.3.2.8.
11
